Kubota Generators - GL Series - 2-Pole Single Phase - 6.5 kVA Output - GL7000


MSRP: $7,830.00
Price: $5,995.00
You Save: $1,835.00 (23 %)
Model Number: GL7000
Manufacturer: Kubota
  • Type : Rotating field single-phase AC generator
  • Frequency (Hz) : 60
  • Standby Output kVA (kW) : 7.0 (7.0)
  • Prime Output kVA (kW) : 6.5 (6.5)
  • Voltage Single Phase : 120/240
  • Voltage - Three Phase : -
  • Armature Connection : Series
  • Phase / Wire : 1-4
  • Power Factor : 1.0
  • No. of Poles : 2
  • Insulation Class : Rotor coil; class F, Stator coil; class B
  • Voltage Regulation (%) : -
  • Type of Coupling : Direct coupled AMPS
  • Single Phase 120V (AMPS) : 27.1 x 2
  • Single Phase 240V (AMPS) : 27.1
  • Three Phase 208V (AMPS) : -
  • Three Phase 480V (AMPS) : -
  • No. of Receptacles
  • 5-15R (GFCI) : N/A
  • 5-20RA (GFCI) : 1
  • 6-15R : N/A
  • L5-20R : -
  • L5-30R : 1
  • L6-30R : 1
  • L14-30R : 1
  • CS-6369 : - Terminal
  • Terminal : Available Diesel Engine
  • Type : Vertical, liquid-cooled, 4-cycle diesel engine
  • Model : Z482
  • No. of Cylinders : 2
  • Bore x Stroke (in.) : (2.6 x 2.7)
  • Displacement (cu. in.) : (29.2)
  • Engine Speed (RPM) : 3600
  • Continuous Rated Output (HP) : (10.9)
  • Lubricant (API classification) : Above CF grade
  • Oil Capacity (quarts) : (0.58)
  • Coolant Capacity (quarts) : (0.98)
  • Starting System : Electric 12 volt DC Set
  • Fuel : Diesel fuel No. 2 (ASTM D975)
  • Fuel Consumption at Full Load (gallons/hour) : (0.69)
  • Fuel Consumption at 3/4 Load (gallons/hour) : (0.55)
  • Fuel Consumption at 1/2 Load (gallons/hour) : (0.45)
  • Fuel Consumption at 1/4 Load (gallons/hour) : (0.38)
  • Fuel Tank Capacity (gallons) : (7.4)
  • Continuous Operation Hours at Full Load : 10.0
  • Continuous Operation Hours at 3/4 Load : 13.3
  • Continuous Operation Hours at 1/2 Load : 16.5
  • Continuous Operation Hours at 1/4 Load : 20.0
  • Battery (Ah/5h) : 38B20R (12v x 28Ah)
  • Dimensions (in.) Height x Width x Height : 42.0 x 24.3 x 27.5
  • Sound Level (Full Load at 23 ft.) dB(A) : 66
  • Emergency Stop System : In case of abnormal: Oil pressure, water temperature, or When the access terminal cover is opened (terminal type only)
Kubota Generator GL Series

1. Compact Design

Low Profile and More Compact
The LOWBOY II series is designed to have the minimum possible height while using vertical diesel engines. This is achieved by direct coupling of the engine crankshaft with the cooling fan. Since they require less space for operation, the range of possible applications has been greatly increased.

2. Easy Maintenance

Easy One-Side Maintenance
Large swing-up side panel enables quick and easy engine inspection and maintenance. Engine oil and coolant drain extensions are provided to ease regularly scheduled maintenance. Oil gauge, oil filter, oil replenishment port, fuel filter, water reserve tank, battery and air cleaner are all located on one side.

3. Safety

Safety Measures
Automatically shuts the engine down if the water temperature is excessive or the oil pressure drops below a safe level. Equipped with a starter safety relay to prevent the starter from engaging after the engine starts up.
Removable Cover for Control Panel
Terminal type is equipped with an output connection cover that will stop the engine immediately when it is opened during operation.
Double Circuit Protectors
In addition to the overall circuit protector, each receptacle also has a circuit protector that will shut the engine down to prevent over current damage.

4. Operator Friendly

Transportability
One-point lifting eye makes it easy to transport all GL series generators. Special forklift openings are provided in the base of the machine.
Longer Continuous Operation
Large-capacity fuel tank (7.4gal; 28L) enables longer continuous operation on a single tank.

5. Quiet

Lower Noise Levels
Four separate features help reduce overall noise levels. First, the large-capacity radiator successfully reduces fan-related noise by direct coupling to the crankshaft with a slower-speed fan. Second, the large-capacity, built-in muffler helps reduce exhaust-related noise. Third, the longer air-cleaner hose reduces air-suction-related noise.

Fourth, the ideally placed inlet vent and its improved design reduce noise coming from the enclosure's opening.

6. ATS

Access Terminals for ATS Make Wiring Easy
Access terminals for Automatic Transfer Switches (ATS) are located behind the control panel.
